Aluminum coil is a metal product that is sheared after rolling and bending processing in a casting and rolling mill. Aluminum coils are widely used in electronics, packaging, construction, machinery, etc.
According to the different metal elements contained in aluminum coils, aluminum coils can be roughly divided into 9 major categories. that is, they can be divided into 9 series: 1000 series aluminum coils, 2000 series aluminum coils, 3000 series aluminum coils, 4000 series aluminum coils, and 5000 series Aluminum coil, 6000 series aluminum coil, 7000 series aluminum coil, 8000 series aluminum coil, 9000 series aluminum coil.
Basic Info.
| Aluminum Coil |
| Aluminium Alloy | Thickness | Width | Temper |
| (mm) | (mm) |
| A1050,A1060,A1070,A1100 | 0.2-8.0 | 20-2300 | O,H12,H14,H16,H18,H22,H24,H26 |
| A3003,A3004,A3105 | 0.2-8.0 | 20-2300 | O,H12,H14,H16,H18,H22,H24,H26 |
| A5052,A5005,A5083,A5754 | 0.2-8.0 | 20-2300 | O,H12,H14,H34,H32,H36,H111,H112 |
| A6061,A6082,A6063 | 0.2-8.0 | 20-2300 | T4,T6,T651 |
| A8011 | 0.2-8.0 | 20-2300 | O,H12,H14,H16,H18,H22,H24,H26 |
| Material process | CC AND DC |
| Customerize size | Size can be produced as per clients requirement |
| Surface | Mill finish ,Color coated(PVDF& PE),Stucco Embossed ,Bright Polish,Anodizing |
| Mirror,Brush,Perforated,Tread plate ,Corrugated etc |
| MOQ per size | 1 ton |
| Delivery time | Within 25 days after receipt the lc or deposit |
| Material Quality | Tension levelled ,flat ,Free of defects like oil stain,Roll Marks,Waves,Dents |
| scratches etc ,A+++ quality, production process passed sgs and bv inspection |
| Application | Construction ,Building,Decoration ,Curtain Wall ,Roofing,Mould,Lighting, |
| curtain wall, ship building,Aircraft,Oil Tank ,Truck Body etc |
| Packing | Standard export worthy wooden pallets |
| and standard packing is about 2 tons/pallet |
| Pallet weight also can be as per client's requirement |
Product Description
| 1)1000 Series Alloy (Generally called commercial pure aluminum,Al>99.0%) |
| Purity | 1050 1050A 1060 1070 1100 |
| Temper | O/H111 H112 H12/H22/H32 H14/H24/H34 H16/
H26/H36 H18/H28/H38 H114/H194, etc. |
| Specification | Thickness≤30mm; Width≤2600mm; Length≤16000mm OR Coil (C) |
| Application | Lid Stock, Industrial Device, Storage, All Kinds of Containers, etc. |
| Feature | Lid Shigh conductivity, good corrosion resistant performance, high latent heat
of melting, high-reflectance, well welding property, low strength, and not
suitable for heat treatments. |
| 2)3000 Series Alloy (Generally called Al-Mn Alloy, Mn is used as main alloy element) |
| Alloy | 3003 3004 3005 3102 3105 |
| Temper | O/H111 H112 H12/H22/H32 H14/H24/H34 H16/H26/
H36 H18/H28/H38 H114/H194, etc. |
| Specification | Thickness≤30mm; Width≤2200mm Length≤12000mm OR Coil (C) |
| Application | Decoration, heat-sink device, external walls, storage, sheets for construction, etc. |
| Feature | Good rust resistance, not suitable for heat treatments, good corrosion resistant
performance, well welding property, good plasticity, low strength but suitable
for cold working hardening |
| 3)5000 Series Alloy (Generally called Al-Mg Alloy, the Mg is used as main alloy element) |
| Alloy | 5005 5052 5083 5086 5182 5754 5154 5454 5A05 5A06 |
| Temper | O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34
H16/H26/H36 H18/H28/H38 H114/H194, etc. |
| Specification | Thickness≤170mm; Width≤2200mm ; Length≤12000mm |
| Application | Marine Grade Plate, Ring-Pull Can End Stock, Ring-Pull Stock, Automobile
Body Sheets, Automobile Inside Board, The Protective Cover On Engine. |
| Feature | All the advantages of normal aluminium alloy, high tensile strength & yield strength,
good corrosion resistant performance, well welding property, well fatigue strength,
and suitable for anodic oxidation. |
| 4)6000 Series Alloy (Generally called Al-Mg-Si Alloy, the Mg and Si are used as main alloy elements ) |
| Alloy | 6061 6063 6082 |
| Temper | O F, etc. |
| Specification | Thickness≤170mm; Width≤2200mm ; Length≤12000mm |
| Application | Automotive, Aluminium For Aviation, Industrial Mould, Mechanical Components,
Transport Ship, Semiconductor Equipments, etc |
| Feature | Good corrosion resistant performance, well welding property, good oxidability,
easy to spray-finishing, well oxidation coloring, good machinability. |
